Storm Valve Subsurface Safety Valve For Well Testing & Well Completion Service

  • 1
  • 2

Brand Name : ZZ TOP OIL TOOLS

Model Number : Storm Valve High Pressure

Certification : ISO, API

Place of Origin : China

MOQ : 1 set

Price : USD 1-10000/set

Payment Terms : L/C, T/T, D/P

Supply Ability : 10 set/month

Delivery Time : 30-50 days

Packaging Details : Pollywood

Product : Subsurface Safety Valve

Application : Oil Well Testing Operation

Usage : Subsurface Control

Size : 4 3/4 inch

Working Pressure : 10000psi

Connection : IF, EUE , CAS

Working Condition : Oil & Gas & H2S service

Working Temperature : Up to 425oF

Contact Now

Storm Valve / Subsurface Safety Valve For Well Testing & Well Completion Service



The Storm Valve is a kind of  safety valve to control the well which is called subsurface safety valve ( SSCV). The storm valve is a combination valve and backoff joint that allows operators to close in a well that is being drilled without having to pull the workstring. This capability is especially useful in offshore operations when storms are expected or when surface equipment, such as blowout preventers, must be repaired. The valve eliminates the hazard of leaving pipe standing in the derrick during a storm.



Features of Storm Valve



  •  The storm valve can save rig time
  •  It is easy to operate the storm valve in oufield
  •  The storm valve can test blowout preventers during drilling operations
  •  The storm valve can increase the rig crew’s safet

Technical parameter of Storm Valve



1 Size 158.8mm(6.25”) 120.7mm(4.75”)
2 ID 50.8mm 31.8mm
3 Length 1737mm 1737mm
4 Working Pressure 70Mpa 70Mpa
5 Tensile Strength 1340KN 770KN
6 Torque Strength 100KN.M 73KN.M
7 Internal Pressure Strength 103.5Mpa 99Mpa
8 External Pressure Strength 98Mpa 92Mpa
9 Service NACE MR0175,Above 175F
10 Working Temperature -29oC~204oC
11 Connection Thread 4 1/2” IF BXP 3 1/2”IF



Storm Valve Subsurface Safety Valve For Well Testing & Well Completion Service  Storm Valve Subsurface Safety Valve For Well Testing & Well Completion Service
