10000psi VR Safety Joint For Drill Stem Testing Tools 5" X10000psi

  • 1
  • 2

Brand Name : ZZ TOP OIL TOOLS

Model Number : VR Safety Joint

Certification : ISO, API

Place of Origin : China

MOQ : 1 set

Price : USD 1-10000/set

Payment Terms : L/C, T/T, D/P

Supply Ability : 10 set/month

Delivery Time : 30-50 days

Packaging Details : Pollywood

Product : VR safety joint

Type : APR Tools

Size : 5 inch

Working Pressure : 10000psi

Application : Oil Well Downhole Testing Service

Connection : IF, EUE , CAS

Working Condition : Oil & Gas & H2S service

Working Temperature : Up to 425oF

Contact Now

VR Safety Joint For Drill Stem Testing Service 5" x10000psi


VR Safety joint is a compact, right-hand safety joint used in the drill stem testing string. It is run immediately above the packer assembly to ensure that a minimum number of tools are left in the hole if it becomes necessary to release the safety joint. The tool’s bypass feature acts as an auxiliary to the Hydrospring tester bypass to allow fluid to pass though the packer while the work string is being pulled out of the hole.
A spline and lug arrangement, joining the male and female parts of the left-hand safety joint thread, lock to prevent unintentional back-off from the tool during normal manipulation of the drill pipe during testing. Because of the spline and lug configuration, the slips must be dropped in place before the drill pipe is lowered after every stand of pipe is pulled out of the hole.


Technical parameter of Tension Sleeve RTTS Safety Joint




1 Nominal Size 5”
2 OD 127.5mm
3 ID 25mm
4 Length 963mm
5 Working Pressure 70Mpa(10000psi)
6 Tensile Strength 1628KN
7 Burst Pressure 113.6Mpa
8 Collapse Pressure 150Mpa
9 Torque Strength 15kN.m
10 Working Temp. -29oC~180oC
11 Service H2S NACE MR0175(Above 175F)
12 Connection Thread EUE/IF/CAS
13 Througth Area 1700mm2


   10000psi VR Safety Joint For Drill Stem Testing Tools 5" X10000psi  10000psi VR Safety Joint For Drill Stem Testing Tools 5" X10000psi
